创建证书

因为要产生 key 信任库，要求的密码至少的 6位数，所以密码设为 123456

首先生成根密钥和根证书
然后生成客户端密钥和客户端证书，使用根证书对应客户端证书签名，将根证书和签名客户端证书添加到密钥库中
最后同上生成服务端签名证书，并将根证书和服务端证书添加到密钥库中。

对应的脚本如下所示：

#!/bin/bash
# 加个前缀
PFX='file'
# Password 这里只能使用单引号
PASS='123456'
echo "---- 产生根相关文件 ----"
echo "创建自签名的根密钥"
openssl genrsa -out ${PFX}.rootkey.pem 2048
echo "生成根证书"
openssl req -x509 -new -key ${PFX}.rootkey.pem -out ${PFX}.root.crt -subj "/C=CN/ST=GD/L=GZ/O=pythonRootCA/OU=RootCA/CN=RootCA"
echo "----- 产生客户端相关文件 -----"
echo "生成客户端密钥"
openssl genrsa -out ${PFX}.clientkey.pem 2048
echo "生成客户端证书请求文件，使用根证书进行签发"
openssl req -new -key ${PFX}.clientkey.pem -out ${PFX}.client.csr -subj "/C=CN/ST=GD/L=GZ/O=BMW/OU=Vehicle/CN=Vehicle1"
echo "用根证书来签发客户端请求文件，生成客户端证书client.crt"
openssl x509 -req -in ${PFX}.client.csr -CA ${PFX}.root.crt -CAkey ${PFX}.rootkey.pem -CAcreateserial -days 3650 -out ${PFX}.client.crt
echo "打包客户端资料为pkcs12格开发者_开发教程式(client.pkcs12)"
openssl pkcs12 -export -in ${PFX}.client.crt -inkey clientkey.pem -out ${PFX}.client.pkcs12 -passin "pass:$PASS" -passout "pass:$PASS"
echo "生成信任客户端的keystore，把根证书以及需要信任的客户端的证书添加到这个keystore"
keytool -importcert -alias ca -file ${PFX}.root.crt -keystore ${PFX}.clienttrust.jks -storepass "$PASS" <<EOF
是
EOF
keytool -importcert -alias clientcert -file ${PFX}.client.crt -keystore ${PFX}.clienttrust.jks -storepass "$PASS"
echo "--------产生服务端相关文件----"
echo "生成服务器端的密匙"
openssl genrsa -out ${PFX}.serverkey.pem 2048
echo "生成服务器端证书的请求文件。请求根证书来签发"
openssl req -new -key ${PFX}.serverkey.pem -out ${PFX}.server.csr -subj "/C=CN/ST=GD/L=GZ/O=BMW/OU=IT/CN=Broker"
echo "用根证书来签发服务器端请求文件，生成服务器端证书server.crt"
openssl x509 -req -in ${PFX}.server.csr -CA ${PFX}.root.crt -CAkey ${PFX}.rootkey.pem -CAcreateserial -days 3650 -out ${PFX}.server.crt
echo "打包服务器端资料为pkcs12格式(server.pkcs12 )"
openssl pkcs12 -export -in ${PFX}.server.crt -inkey ${PFX}.serverkey.pem -out ${PFX}.server.pkcs12 -passin "pass:$PASS" -passout "pass:$PASS"
echo "生成信任服务器端的keystore，把根证书以及需要信任的服务端的证书添加到这个keystore"
keytool -importcert -alias ca -file ${PFX}.root.crt -keystore ${PFX}.servertrust.jks -storepass "$PASS" <<EOF
是
EOF
keytool -importcert -alias servercert -file ${PFX}.server.crt -keystore ${PFX}.servertrust.jks -storepass "$PASS"

生成的文件目录，如下图所示：

一文详解如何通过Java实现SSL交互功能

#编码

编写 SSL Server

import Javax.net.ssl.SSLContext;
import javax.net.ssl.SSLServerSocket;
import java.net.Socket;

public class SSLServer {
    private SSLServerSocket sslServerSocket;

    public static void main(String[] args) throws Exception {
        SSLServer server = new SSLServer();
        server.initTestServer();
        server.process();
    }

    private SSLServerSocket initTestServer() throws Exception {
    // ssl-cert 放在 测试 resources 目录下
        String certDic = SSLServer.class.getClassLoader().getResource("ssl-cert").getPath();
        sslServerSocket = initSocket(certDpythonic + "/file.server.pkcs12",
                certDic + "/file.clienttrust.jks",
                "123456");
    // 如果为 false 表示单向认证，否则为双向认证
        sslServerSocket.setNeedClientAuth(false);
        System.out.println("Server test initialted!");
        return sslServerSocket;
    }

    private SSLServerSocket initSocket(String keyPath, String trustPath, String password) throws Exception {
        SSLContext context = SSLContext.getInstance("TLSv1.2");
        char[] keystorePass = password.toCharArray();
        context.init(SSLUtils.creatKey(keyPath, keystorePass).getKeyManagers(),
                SSLUtils.creatTrustJks(trustPath, keystorePass).getTrustManagers(),
                null);
        return (SSLServerSocket) context.getServerSocketFactory().createServerSocket(9999);
    }

//服务端回复客户端
    private void process() throws Exception {
        String bye = "Hello, I am Server!";
        while (true) {
            Socket socket = sslServerSocket.accept();
            System.out.println("Received: " + SSLUtils.read(socket));
            SSLUtils.write(bye, socket);
        }
    }
}

编写 SSL Client

import javax.net.ssl.KeyManager;
import javax.net.ssl.KeyManagerFactory;
import javax.net.ssl.SSLContext;
import javax.net.ssl.SSLSocket;
import javax.net.ssl.TrustManager;
import javax.net.ssl.TrustManagerFactory;

public class SSLClient {
    private SSLSocket sslSocket;

    public static void main(String[] args) throws Exception {
        SSLClient client = new SSLClient();
        client.init();
        client.process();
    }

    privjavascriptate void init() throws Exception {
     // ssl-cert 放在 测试 resources 目录下
        String certDic = this.getClass().getClassLoader().getResource("ssl-cert").getPath();
        initSocket(certDic + "/file.server.pkcs12", certDic + "/file.servertrust.jks", "123456");
        System.out.println("Client initiated.");
    }

    private void initSocket(String keystorePath, String trustStorePath, String password) throws Exception {
        char[] keystorePass = password.toCharArray();

        KeyManager[] keyManagers = null;
        KeyManagerFactory keyManagerFactory = SSLUtils.creatKey(keystorePath, keystorePass);
        if (keyManagerFactory != null) {
            keyManagers = keyManagerFactory.getKeyManagers();
        }

        TrustManager[] trustManagers = null;
        TrustManagerFactory trustManagerFactory = SSLUtils.creatTrustJks(trustStorePath, keystorePass);
        if (trustManagerFactory != null) {
            trustManagers = trustManagerFactory.getTrustManagers();
        }

        SSLContext context = SSLContext.getInstance("TLSv1.2");
        context.init(keyManagers, trustManagers, null);

        String host = "127.0.0.1";
        sslSocket = (SSLSocket) context.getSocketFactory().createSocket(host, 9999);
    }

    public void process() throws Exception {
        String hello = "Client Hello";
        SSLUtils.write(hello, sslSocket);
        System.out.println(SSLUtils.read(sslSocket));
    }

}

通用编码

import org.apache.commons.lang3.StringUtils;

import javax.net.ssl.KeyManagerFactory;
import javax.net.ssl.TrustManagerFactojavascriptry;
import java.io.FileInputStream;
import java.io.InputStream;
import java.io.OutputStream;
import java.net.Socket;
import java.nio.charset.StandardCharsets;
import java.security.KeyStore;

public class SSLUtils {

    public static void write(String message, Socket sslSocket) throws Exception {
        OutputStream out = sslSocket.getOutputStream();
        byte[] messageBytes = message.getBytes(StandardCharsets.UTF_8);
        out.write(messageBytes, 0, messageBytes.length);
        out.flush();
    }

    public static String read(Socket sslSocket) throws Exception {
        InputStream in = sslSocket.getInputStream();
        byte[] buffer = new byte[50];
        in.read(buffer);
        return new String(buffer);
    }

    public static KeyManagerFactory creatKey(String keystorePath, char[] keystorePass) throws Exception {
        if (StringUtils.isEmpty(keystorePath)) {
            return null;
        }
        KeyManagerFactory kmf = KeyManagerFactory.getInstance("sunx509");
        kmf.init(loadKeyStore(keystorePath, keystorePass), keystorePass);
        return kmf;
    }

    public static TrustManagerFactory creatTrustJks(String trustClientKeystorePath, char[] keystorePass) throws Exception {
        if (StringUtils.isEmpty(trustClientKeystorePath)) {
            return null;
        }
        TrustManagerFactory tmf = TrustManagerFactory.getInstance("sunx509");
        tmf.init(loadKeyStore(trustClientKeystorePath, keystorePass));
        returnjavascript tmf;
    }

    private static KeyStore loadKeyStore(String keystorePath, char[] keystorePass) throws Exception {
        KeyStore serverKeyStore = KeyStore.getInstance(StringUtils.substringAfterLast(keystorePath, "."));
        serverKeyStore.load(new FileInputStream(keystorePath), keystorePass);
        return serverKeyStore;
    }
}
