websocket+redis动态订阅和动态取消订阅的实现示例

开发者 https://www.devze.com 2022-11-30 02:25 出处：网络 作者： 柯腾_
目录原理redis订阅监听类webSocket订阅推送类项目地址Update20220415原理websocket的订阅就是在前后端建立ws连接之后，前端通过发送一定格式的消息，后端解析出来去订阅或者...
相关专题：websocket+redis动态取消订阅websocketredis动态订阅
目录
  • 原理
  • redis订阅监听类
  • webSocket订阅推送类
  • 项目地址
  • Update20220415

原理

websocket的订阅就是在前后端建立ws连接之后，前端通过发送一定格式的消息，后端解析出来去订阅或者取消订阅redis频道。

订阅频道消息格式:

{
    "cmd":"subscribe",
    "topic":[
        "topic_name"
    ]
}

模糊订阅格式

{
    "cmd":"psubscribe",
    "topic":[
        "topic_name"
    ]
}

取消订阅格式

{
    "cmd":"unsubscribe",
    "topic":[
        "topic_name"
    ]
}

两个核心类，一个是redis的订阅监听类，一个是websocket的发布订阅类。

redis订阅监听类

package com.curtain.core;

import com.curtain.config.GetBeanUtil;
import lombok.extern.slf4j.Slf4j;
import org.springframework.stereotype.Component;
import redis.clients.jedis.Jedis;
import redis.clients.jedis.JedisPool;
import redis.clients.jedis.JedisPubSub;

import java.util.Arrays;

/**
* @Author Curtain
* @Date 2021/6/7 14:27
* @Description
*/
@Component
@Slf4j
public class RedisPubSub extends JedisPubSub {
  private JedisPool jedisPool = GetBeanUtil.getBean(JedisPool.class);
  private Jedis jedis;

  //订阅
  public void subscribe(String... channels) {
    jedis = jedisPool.getResource();
    try {
      jedis.subscribe(this, channels);
    } catch (Exception e) {
      log.error(e.getMessage());
      if (jedis != null)
        jedis.close();
      //遇到异常后关闭连接重新订阅
      log.info("监听遇到异常，四秒后重新订阅频道：");
      Arrays.asList(channels).forEach(s -> {log.info(s);});
      try {
        Thread.sleep(4000);
      } catch (InterruptedException interruptedException) {
        interruptedException.printStackTrace();
      }
      subscribe(channels);
    }
  }

  //模糊订阅
  public void psubscribe(String... channels) {
    Jedis jedis = jedisPool.编程客栈getResource();
    try {
      jedis.psubscribe(this, channels);
    } catch (ArithmeticException e) {//取消订阅故意造成的异常
      if (jedis != null)
        jedis.close();
    } catch (Exception e) {
      log.error(e.getMessage());
      if (jedis != null)
        jedis.close();
      //遇到异常后关闭连接重新订阅
      log.info("监听遇到异常，四秒后重新订阅频道：");
      Arrays.asList(channels).forEach(s -> {log.info(s);});
      try {
        Thread.sleep(4000);
      } catch (InterruptedException interruptedException) {
        interruptedException.printStackTrace();
      }
      psubscribe(channels);
    }
  }

  public void unsubscribeAndClose(String... channels){
    unsubscribe(channels);
    if (jedis != null && !isSubscribed())
      jedis.close();
  }

  public void punsubscribeAndClose(String... channels){
    punsubscribe(channels);
    if (jedis != null && !isSubscribed())
      jedis.close();
  }

  @Override
  public void onSubscribe(String channel, int subscribedChannels) {
    log.info("subscribe redis channel：" + channel + ", 线程id：" + Thread.currentThread().getId());
  }

  @Override
  public void onPSubscribe(String pattern, int subscribedChannels) {
    log.info("psubscribe redis channel：" + pattern + ", 线程id：" + Thread.currentThread().getId());
  }

  @Override
  public void onPMessage(String pattern, String channel, String message) {
    log.info("receive from redis channal: " + channel + ",pattern: " + pattern + ",message：" + message + ", 线程id：" + Thread.currentThread().getId());
    WebSocketServer.publish(message, pattern);
    WebSocketServer.publis开发者_Kafkah(message, channel);

  }

  @Override
  public void onMessage(String channel, String message) {
    log.info("receive from redis channal: " + channel + ",message：" + message + ", 线程id：" + Thread.currentThread().getId());
    WebSocketServer.publish(message, channel);
  }

  @Override
  public void onUnsubscribe(String channel, int subscribedChannels) {
    log.info("unsubscribe redis channel：" + channel);
  }

  @Override
  public void onPUnsubscribe(String pattern, int subscribedChannels) {
    log.info("punsubscribe redis channel：" + pattern);
  }
}

1.jedis监听redis频道的时候如果遇见异常会关闭连接导致后续没有监听该频道，所以这里在subscribe捕获到异常的时候会重新创建一个jedis连接订阅该redis频道。

webSocket订阅推送类

这个类会有两个ConcurrentHashMap<String, ConcurrentHashMap<String, WebSocketServer>>类型类变量，分别存储订阅和模糊订阅的信息。

外面一层的String对应的值是topic_name,里面一层的String对应的值是sessionId。前端发送过来的消息里面对应的这三类操作其实就是对这两个map里面的。

还有个ConcurrentHashMap<String, RedisPubSub>类型的变量，存储的是事件-RedisPubSub，便于取消订阅的时候找到监听该频道（事件）的RedisPubSub对象。

信息进行增加或者删除;后端往前端推送数据也会根据不同的topic_name推送到不同的订阅者这边。

package com.curtain.core;

import com.alibaba.fastjson.JSON;
import com.curtain.config.WebsocketProperties;
import com.curtain.service.Cancelable;
import com.curtain.service.impl.TaskExecuteService;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;

import javax.websocket.*;
import javax.websocket.server.ServerEndpoint;
import java.io.IOException;
import java.io.UnsupportedEncodingException;
import java.nio.ByteBuffer;
import java.util.*;
import java.util.concurrent.ConcurrentHashMap;


/**
* @Author Curtain
* @Date 2021/5/14 16:49
* @Description
*/
@ServerEndpoint("/ws")
@Component
@Slf4j
public class WebSocketServer {
  /**
  * concurrent包的线程安全Set，用来存放每个客户端对应的MyWebSocket对象。
  */
  private static volatile ConcurrentHashMap<String, ConcurrentHashMap<String, WebSocketServer>> webSocketMap = new ConcurrentHashMap<>();
  /**
  * 存放psub的事件
  **/
  private static volatile ConcurrentHashMap<String, ConcurrentHashMap<String, WebSocketServer>> pWebSocketMap = new ConcurrentHashMap<>();
  /**
  * 存放topic(pattern)-对应的RedisPubsub
  */
  private static volatile ConcurrentHashMap<String, RedisPubSub> redisPubSubMap = new ClOBxPoncurrentHashMap<>();
  /**
  * 与某个客户端的连接会话，需要通过它来给客户端发送数据
  */
  private Session session;
  private String sessionId = "";
  //要注入的对象
  private static TaskExecuteService executeService;
  private static WebsocketProperties properties;

  private Cancelable cancelable;

  @Autowired
  public void setTaskExecuteService(TaskExecuteService taskExecuteService) {
    WebSocketServer.executeService = taskExecuteService;
  }

  @Autowired
  public void setWebsocketProperties(WebsocketProperties properties) {
    WebSocketServer.properties = properties;
  }

  /**
  * 连接建立成功调用的方法
  */
  @OnOpen
  public void onOpen(Session session) {
    this.session = session;
    this.sessionId = session.getId();
    //构造推送数据
    Map pubHeader = new HashMap();
    pubHeader.put("name", "connect_status");
    pubHeader.put("type", "create");
    pubHeader.put("from", "pubsub");
    pubHeader.put("time", new Date().getTime() / 1000);
    Map pubPayload = new HashMap();
    pubPayload.put("status", "success");
    Map pubMap = new HashMap();
    pubMap.put("header", pubHeader);
    pubMap.put("payload", pubPayload);
    sendMessage(JSON.toJSONString(pubMap));
    cancelable = executeService.runPeriodly(() -> {
      try {
        if (cancelable != null && !session.isOpen()) {
          log.info("断开连接，停止发送ping");
          cancelable.cancel();
        } else {
          String data = "ping";
          ByteBuffer payload = ByteBuffer.wrap(data.getBytes());
          session.getBasicRemote().sendPing(payload);
        }
      } catch (IOException e) {
        e.printStackTrace();
      }
    }, properties.getPeriod());

  }

  @OnMessage
  public void onMessage(String message) {
    synchronized (session) {
      Map msgMap = (Map) JSON.parse(message);
      String cmd = (String) msgMap.get("cmd");
      //订阅消息
      if ("subscribe".equals(cmd)) {
        List<String> topics = (List<String>) msgMap.get("topic");
        //本地记录订阅信息
        for (int i = 0; i < topics.size(); i++) {
          String topic = topics.get(i);
          log.info("============================subscribe-start============================");
          log.info("sessionId：" + this.sessionId + "，开始订阅：" + topic);
          if (webSocketMap.containsKey(topic)) {//有人订阅过了
            webSocketMap.get(topic).put(this.sessionId, this);
          } else {//之前还没人订阅过，所以需要订阅redis频道
            ConcurrentHashMap<String, WebSocketServer> map = new ConcurrentHashMap<>();
            map.put(this.sessionId, this);
            webSocketMap.put(topic, map);
            new Thread(() -> {
              RedisPubSub redisPubSub = new RedisPubSub();
              //存入map
              redisPubSubMap.put(topic, redisPubSub);
              redisPubSub.subscribe(topic);
            }).start();
          }
          log.info("sessionId：" + this.sessionId + "，完成订阅：" + topic);
          log();
          log.info("============================subscribe-end============================");
        }
      }
      //psubscribe
      if ("psubscribe".equals(cmd)) {
        List<String> topics = (List<String>) msgMap.get("topic");
        //本地记录订阅信息
        for (int i = 0; i < topics.size(); i++) {
          String topic = topics.get(i);
          log.info("============================psubscribe-start============================");
          log.info("sessionId：" + this.sessionId + "，开始模糊订阅：" + topic);
          if (pWebSocketMap.containsKey(topic)) {//有人订阅过了
            pWebSocketMap.get(topic).put(this.sessionId, this);
          } else {//之前还没人订阅过，所以需要订阅redis频道
            ConcurrentHashMap<String, WebSocketServer> map = new ConcurrentHashMap<>();
            map.put(this.sessionId, this);
            pWebSocketMap.put(topic, map);
            new Thread(() -> {
              RedisPubSub redisPubSub = new RedisPubSub();
              //存入map
              redisPubSubMap.put(topic, redisPubSub);
              redisPubSub.psubscribe(topic);
            }).start();
          }
          log.info("sessionId：" + this.sessionId + "，完成模糊订阅：" + topic);
          log();
          log.info("============================psubscribe-end============================");
        }
      }
      //取消订阅
      if ("unsubscribe".equals(cmd)) {
        List<String> topics = (List<String>) msgMap.get("topic");
        //删除本地对应的订阅信息
        for (String topic : topics) {
          log.info("============================unsubscribe-start============================");
          log.info("sessionId：" + this.sessionId + "，开始删除订阅：" + topic);
          if (webSocketMap.containsKey(topic)) {
            ConcurrentHashMap<String, WebSocketServer> map = webSocketMap.get(topic);
            map.remove(this.sessionId);
            if (map.size() == 0) {//如果这个频道没有用户订阅了，则取消订阅该redis频道
              webSocketMap.remove(topic);
              redisPubSubMap.get(topic).unsubscribeAndClose(topic);
              redisPubSubMap.remove(topic);
            }
          }
          if (pWebSocketMap.containsKey(topic)) {
            ConcurrentHashMap<String, WebSocketServer> map = pWebSocketMap.get(topic);
            map.remove(this.sessionId);
            if (map.size() == 0) {//如果这个频道没有用户订阅了，则取消订阅该redis频道
              pWebSocketMap.remove(topic);
              redisPubSubMap.get(topic).punsubscribeAndClose(topic);
              redisPubSubMap.remove(topic);
            }
          }
          log.info("sessionId：" + this.sessionId + "，完成删除订阅：" + topic);
          log();
          log.info("============================unsubscribe-end============================");
        }
      }
    }
  }

  @OnMessage
  public void onPong(PongMessage pongMessage) {
    try {
      log.debug(new String(pongMessage.getApplicationData().array(), "utf-8") + "接收到pong");
    } catch (UnsupportedEncodingException e) {
      e.printStackTrace();
    }
  }

  /**
  * 连接关闭调用的方法
  */
  @OnClose
  public void onClose() {
    synchronized (session) {
      log.info("====http://www.devze.com========================onclose-start============================");
      //删除订阅
      Iterator iterator = webSocketMap.keySet().iterator();
      while (iterator.hasNext()) {
        String topic = (String) iterator.next();
        ConcurrentHashMap<String, WebSocketServer> map = webSocketMap.get(topic);
        map.remove(this.sessionId);
        if (map.size() == 0) {//如果这个频道没有用户订阅了，则取消订阅该redis频道
          webSocketMap.remove(topic);
          redisPubSubMap.get(topic).unsubscribeAndClose(topic);
          redisPubSubMap.remove(topic);
        }
      }
      //删除模糊订阅
      Iterator iteratorP = pWebSocketMap.keySet().iterator();
      while (iteratorP.hasNext()) {
        String topic = (String) iteratorP.next();
        ConcurrentHashMap<String, WebSocketServer> map = pWebSocketMap.get(topic);
        map.remove(this.sessionId);
        if (map.size() == 0) {//如果这个频道没有用户订阅了，则取消订阅该redis频道
          pWebSocketMap.remove(topic);
          redisPubSubMap.get(topic).punsubscribeAndClose(topic);
          redisPubSubMap.remove(topic);
        }
      }
      log.info("sessionId：" + this.sessionId + "，断开连接：");
      //debug
      log();
      log.info("============================onclose-end============================");
    }
  }


  /**
  * @param session
  * @param error
  */
  @OnError
  public void onError(Session session, Throwable error) {
    synchronized (session) {
      log.info("============================onError-start============================");
      log.error("用户错误,sessionId:" + session.getId() + ",原因:" + error.getMessage());
      error.printStackTrace();
      log.info("关闭错误用户对应的连接");
      //删除订阅
      Iterator iterator = webSocketMap.keySet().iterator();
      while (iterator.hasNext()) {
        String topic = (String) iterator.next();
        ConcurrentHashMap<String, WebSocketServer> map = webSocketMap.get(topic);
        map.remove(this.sessionId);
        if (map.size() == 0) {//如果这个频道没有用户订阅了，则取消订阅该redis频道
          webSocketMap.remove(topic);
          redisPubSubMap.get(topic).unsubscribeAndClose(topic);
          redisPubSubMap.remove(topic);
        }
      }
      //删除模糊订阅
      Iterator iteratorP = pWebSocketMap.keySet().iterator();
      while (iteratorP.hasNext()) {
        String topic = (String) iteratorP.next();
        ConcurrentHashMap<String, WebSocketServer> map = pWebSocketMap.get(topic);
        map.remove(this.sessionId);
        if (map.size() == 0) {//如果这个频道没有用户订阅了，则取消订阅该redis频道
          pWebSocketMap.remove(topic);
          redisPubSubMap.get(topic).punsubscribeAndClose(topic);
          redisPubSubMap.remove(topic);
        }
      }
      log.info("完成错误用户对应的连接关闭");
      //debug
      log();
      log.info("============================onError-end============================");
    }
  }

  /**
  * 实现服务器主动推送
  */
  public void sendMessage(String message) {
    synchronized (session) {
      try {
        this.session.getBasicRemote().sendText(message);
      } catch (IOException e) {
        e.printStackTrace();
      }
    }
  }

  public static void publish(String msg, String topic) {
    ConcurrentHashMap<String, WebSocketServer> map = webSocketMap.get(topic);
    if (map != null && map.values() != null) {
      for (WebSocketServer webSocketServer : map.values())
        webSocketServer.sendMessage(msg);
    }
    map = pWebSocketMap.get(topic);
    if (map != null && map.values() != null) {
      for (WebSocketServer webSocketServer : map.values())
        webSocketServer.sendMessage(msg);
    }
  }

  private void log() {
    log.info("<<<<<<<<<<<完成操作后，打印订阅信息开始>>>>>>>>>>");
    Iterator iterator1 = webSocketMap.keySet().iterator();
    while (iterator1.hasNext()) {
      String topic = (String) iterator1.next();
      log.info("topic：" + topic);
      Iterator iterator2 = webSocketMap.get(http://www.devze.comtopic).keySet().iterator();
      while (iterator2.hasNext()) {
        String session = (String) iterator2.next();
        log.info("订阅" + topic + "的sessionId：" + session);
      }
    }
    log.info("<<<<<<<<<<<完成操作后，打印订阅信息结束>>>>>>>>>>");
  }
}

项目地址

上面介绍了核心代码，下面是完整代码地址

https://github.com/Curtain-Wang/websocket-redis-subscribe.git

Update20220415

参考评论区老哥的建议，将redis订阅监听类里面的subscribe和psubscribe方法调整如下：

  //订阅
  @Override
  public void subscribe(String... channels) {
    boolean done = true;
    while (done){
      Jedis jedis = jedisPool.getResource();
      try {
        jedis.subscribe(this, channels);
        done = false;
      } catch (Exception e) {
        log.error(e.getMessage());
        if (jedis != null)
          jedis.close();
        //遇到异常后关闭连接重新订阅
        log.info("监听遇到异常，四秒后重新订阅频道：");
        Arrays.asList(channels).forEach(s -> {log.info(s);});
        try {
          Thread.sleep(4000);
        } catch (InterruptedException interruptedException) {
          interruptedException.printStackTrace();
        }
      }
    }
  }
  //模糊订阅
  @Override
  public void psubscribe(String... channels) {
    boolean done = true;
    while (done){
      Jedis jedis = jedisPool.getResource();
      try {
        jedis.psubscribe(this, channels);
        done = false;
      } catch (Exception e) {
        log.error(e.getMessage());
        if (jedis != null)
       编程客栈   jedis.close();
        //遇到异常后关闭连接重新订阅
        log.info("监听遇到异常，四秒后重新订阅频道：");
        Arrays.asList(channels).forEach(s -> {log.info(s);});
        try {
          Thread.sleep(4000);
        } catch (InterruptedException interruptedException) {
          interruptedException.printStackTrace();
        }
      }
    }
  }

到此这篇关于websocket+redis动态订阅和动态取消订阅的实现示例的文章就介绍到这了,更多相关websocket redis动态订阅 内容请搜索我们以前的文章或继续浏览下面的相关文章希望大家以后多多支持我们！

0

上一篇:

:下一篇

更多 数据库 相关资讯：

精彩评论

暂无评论...
登录 注册
Qedev.com
验证码 换一张
取 消

    关注公众号

    热门标签

    图文推荐

    MySQL字符串日期格式转换的几种常用方法例子解析

    MySQL字符串日期格式转换的几种常用方法例子解析
    详解Sqlsugar调用Oracle的存储过程

    详解Sqlsugar调用Oracle的存储过程
    SpringBoot集成Mongodb的操作方法

    SpringBoot集成Mongodb的操作方法
    如何用PyMongo在Python中操作MongoDB的超完整指南

    如何用PyMongo在Python中操作MongoDB的超完整指南
    Vcenter清理/storage/archive空间的处理方式

    Vcenter清理/storage/archive空间的处理方式
    mysql插入带emoji表情的数据报错问题

    mysql插入带emoji表情的数据报错问题
    Mysql允许他人访问本机数据库的实现步骤

    Mysql允许他人访问本机数据库的实现步骤
    Docker安装MongoDB的过程(mongo.latest)

    Docker安装MongoDB的过程(mongo.latest)

    开发者开发者网给大家分享系统运维,大数据运维,云计算,编程开发技巧,路由交换,运维和开发相关的资讯及技术文章，同时StackOverflow中文社区，知识经验交流分享。

    法律声明：本站内容均为网友上传，网站举办方负责审核和监督，如存在版权或非法内容，欢迎举报，我们将尽快予以删除。邮箱：devze@qq.com

    Copyright © 2018-2020 开发者. All rights reserved. Powered by 开发者ICP备案号: 京ICP备10032868号-9
